JGGR鍍錫導體耐高溫硅橡膠電纜
廠家現貨AGR 硅橡膠絕緣鍍錫耐高溫電線 硅膠柔軟高溫線
F46規范平方鍍錫電線耐高溫電纜鐵氟龍線4平方氟塑料
聚四氟織造屏蔽線AFP-250-2(鍍銀)
產品類型:AFP-250-2(鍍銀)
履行規范:Q/RM-F—4-2008
產品特性:
1、額外電壓:300-500V
2、工作溫度:-65~+200℃/250℃
3、導 體:絞合鍍錫或鍍銀銅線
4、絕 緣:PFA
運用特性
1．額外電壓：U0/U 0.6/1KV，最高工作溫度： 180℃ 最低環境溫度：固定敷設-60，
2．電纜裝置敷設溫度應不低于-25℃。
3．電纜答應曲折半徑：電纜最小為電纜外徑的10倍
JGGR硅橡膠電纜根本類型及稱號
|
類型 |
產品稱號 |
| KGG | 銅芯硅橡膠絕緣硅橡膠護套操控電纜 |
| KGGP | 銅芯硅橡膠絕緣護套織造屏蔽操控電纜 |
| KGG22 | 銅芯硅橡膠絕緣硅橡膠護套鋼帶鎧裝操控電纜 |
| KGGR | 銅芯硅橡膠絕緣硅橡膠護套操控軟電纜 |
| KGG32 | 銅芯硅橡膠絕緣硅橡膠護套細鋼絲鎧裝操控電纜 |
|
YGC |
硅橡膠絕緣硅橡膠護套電力電纜http://www.anhdl.com |
|
YGCR |
硅橡膠絕緣硅橡膠護套移動用電力軟電纜 |
|
YGCP |
硅橡膠絕緣硅橡膠護套銅織造屏蔽電力電纜 |
|
YGC22 |
硅橡膠絕緣硅橡膠護套鋼帶鎧裝電力電纜 |
|
JGG |
硅橡膠絕緣硅橡膠護套裝置線 |
|
JGGR |
硅橡膠絕緣硅橡膠護套移動用裝置軟線 |
|
JGGP |
硅橡膠絕緣硅橡膠護套銅織造屏蔽裝置線 |
|
JHXG |
硅橡膠絕緣電機引接線http://www.anhdl.com |
補白：阻燃型硅橡膠電纜類型前加ZR，導體線芯中銅絲能夠選用鍍錫。
KGG32硅橡膠操控電纜代號稱號和意義
|
代號 |
代號意義 |
|
Y |
系列代號（移動軟電纜） |
|
G |
硅橡膠 |
|
C |
重型 |
|
22 |
鋼帶鎧裝 |
|
P |
銅織造屏蔽 |
|
R |
多股絞合導體 |
|
B |
扁平電纜 |
JGGP硅橡膠電纜|JGGP硅橡膠電纜廠家供給首要技術指標
1．制品電纜導體（R類）直流電阻（契合GB3956規則）參照附錄A表1和表2。
2．20℃時絕緣電阻不小于100MΩ/KM
3．制品電纜飽嘗溝通50HZ3.5KV/5min電壓實驗不擊穿。
JGGR硅橡膠電纜|JGGR硅橡膠電纜廠家修改標準及結構參數
|
線芯*標稱截面（mm2） |
導體結構 （根數*直徑） （B/R） mm |
電纜最大外徑 |
參閱分量（kg/km） |
||
|
YGC JGGF |
YGCR JGGFR |
YGCR JGGFR |
YGC22 JGG22 |
||
|
1*1.5 http://www.anhdl.com |
19*0.32/48*0.20 |
3.2 |
3.5 |
27.5 |
|
|
1*2.5 |
19*0.41/51*0.25 |
3.7 |
3.9 |
38.6 |
|
|
1*4 |
19*0.52/82*0.25 |
4.6 |
5.2 |
55.5 |
|
|
1*6 |
19*0.65/123*0.25 |
5.6 |
6.5 |
77.7 |
|
|
1*10 |
48*0.52/204*0.25 |
7.2 |
7.8 |
132 |
|
|
1*16 |
75*0.52/323*0.25 |
8.2 |
9.0 |
188 |
|
|
1*25 |
108*0.52/513*0.25 |
10.2 |
11.0 |
312 |
|
|
1*35 |
108*0.65/722*0.25 |
112 |
12.0 |
408 |
|
|
1*50 |
10*2.52/1026*0.25 |
13.5 |
14.5 |
554 |
|
|
1*70 |
19*2.16/1406*0.25 |
16.5 |
17.5 |
762 |
|
|
1*95 |
19*2.52/486*0.50 |
19.0 |
20.5 |
1045 |
|
|
1*120 |
24*2.52/608*0.50 |
20.0 |
22.0 |
1281 |
|
|
1*150 |
30*2.52/760*0.50 |
21.0 |
24.2 |
1612 |
|
|
1*185 |
37*2.52/945*0.50 |
25.0 |
28.0 |
1981 |
|
|
2*2.5 |
7*0.68/51*0.25 |
10.5 |
11.2 |
158 |
272 |
|
2*4 |
19*0.52/82*0.25 |
12 |
13.2 |
210 |
347 |
|
2*6 |
19*0.65/123*0.25 |
14.0 |
15.3 |
263 |
407 |
|
2*10 |
7*1.37/204*0.25 |
17.8 |
18.9 |
394 |
562 |
|
2*16 |
7*1.70/323*0.25 |
20.0 |
21.2 |
540 |
724 |
|
2*25 |
7*2.15/513*0.25 |
23.0 |
24.5 |
794 |
828 |
|
2*35 |
7*2.52/722*0.25 |
25.7 |
26.3 |
1037 |
1037 |
|
2*50 |
10*2.52/1026*0.25 |
26.0 |
27.5 |
1236 |
1385 |
|
2*70 |
19*2.16/1406*0.25 |
27.0 |
28.9 |
1647 |
1792 |
|
2*95 |
19*2.52/486*0.50 |
32.0 |
33.9 |
2189 |
2654 |
|
2*120 |
24*2.52/608*0.50 |
45.0 |
48.0 |
2640 |
3180 |
|
2*150 |
30*2.52/760*0.50 |
52.0 |
57.0 |
3280 |
3920 |
|
2*185 |
37*2.52/945*0.50 |
60.0 |
65.0 |
4006 |
4768 |
|
3*1.5 |
7*0.52/48*0.20 |
9.7 |
10.7 |
150 |
291 |
|
3*2.5 |
7*0.68/51*0.25 |
11.7 |
12.2 |
196 |
342 |
|
3*4 |
19*0.52/82*0.25 |
12.6 |
13.5 |
274 |
444 |
|
3*6 |
19*0.65/123*0.25 |
14.8 |
16.2 |
350 |
531 |
|
3*10 |
7*1.37/204*0.25 |
20.0 |
22.0 |
539 |
737 |
|
3*16 |
7*1.70/323*0.25 |
22.0 |
24.5 |
740 |
972 |
|
3*25 |
7*2.15/513*0.25 |
25.3 |
27.0 |
1139 |
1372 |
|
3*35 |
7*2.52/722*0.25 |
28.0 |
31.5 |
1480 |
1729 |
|
3*50 |
10*2.52/1026*0.25 |
32.0 |
37.5 |
1900 |
2405 |
|
3*70 |
19*2.16/1406*0.25 |
41.0 |
50.0 |
4061 |
3087 |
|
3*95 |
19*2.52/486*0.50 |
45.0 |
55.0 |
997 |
4003 |
|
3*120 |
24*2.52/608*0.50 |
50.0 |
60.0 |
4060 |
4887 |
|
3*150 |
30*2.52/760*0.50 |
60.0 |
65.0 |
5197 |
2995 |
|
3*185 |
37*2.52/945*0.50 |
65.0 |
70.0 |
6279 |
7262 |
|
3*4+1*2.5 |
19*0.52/82*0.25 |
14.5 |
15.5 |
320 |
481 |
|
3*6+1*4 |
19*0.65/123*0.25 |
16.2 |
17.8 |
423 |
597 |
|
3*10+1*6 |
7*1.37/204*0.25 |
21.0 |
23.0 |
630 |
827 |
|
3*16+1*10 |
7*1.70/323*0.25 |
23.0 |
25.0 |
888 |
1255 |
|
3*25+1*16 |
7*2.15/513*0.25 |
27.0 |
29.0 |
1375 |
1578 |
|
3*35+1*16 |
7*2.52/722*0.25 |
32.3 |
35.0 |
1690 |
1927 |
|
3*50+1*25 |
10*2.52/1026*0.25 |
36.0 |
40.0 |
2175 |
2760 |
|
3*70+1*35 |
19*2.16/1406*0.25 |
40.0 |
44.0 |
2950 |
3546 |
|
3*95+1*50 |
19*2.52/486*0.50 |
46.0 |
52.0 |
3950 |
4670 |
|
24*2.52/608*0.50 |
51.0 |
55.0 |
4800 |
5745 |
|
|
3*150+1*70 |
30*2.52/760*0.50 |
56.0 |
60.0 |
5810 |
6862 |
|
3*185+1*95 |
37*2.52/945*0.50 |
66.0 |
70.0 |
7200 |
8394 |
|
4*4 |
19*0.52/82*0.25 |
14.2 |
16.2 |
352 |
515 |
|
4*6 |
19*0.65/123*0.25 |
17.1 |
19.0 |
450 |
629 |
|
4*10 |
7*1.37/204*0.25 |
22.1 |
24.0 |
672 |
881 |
|
4*16 |
7*1.70/323*0.25 |
24.5 |
26.5 |
952 |
1176 |
|
4*25 |
7*2.15/513*0.25 |
27.0 |
31.5 |
1476 |
1673 |
|
4*35 |
7*2.52/722*0.25 |
33.0 |
35.5 |
1876 |
2142 |
|
4*50 |
10*2.52/1026*0.25 |
39.0 |
41.0 |
2392 |
2982 |
|
4*70 |
19*2.16/1406*0.25 |
41.0 |
44.0 |
3300 |
3871 |
|
4*95 |
19*2.52/486*0.50 |
47.0 |
50.0 |
4300 |
5094 |
|
4*120 |
24*2.52/608*0.50 |
49.0 |
54.0 |
5380 |
6187 |
|
4*150 |
30*2.52/760*0.50 |
56.0 |
60.0 |
6750 |
7596 |
|
4*185 |
37*2.52/945*0.50 |
68.0 |
72.0 |
8190 |
9194 |
|
我公司出產五芯等截面電纜和3+2結構電纜結構參數不在此表中。 http://www.anhdl.com |
|||||
|
標稱截面mm2 |
芯數結構根/mm | 電纜外徑 mm | 分量kg/km | 20℃ 時導體電阻（Ω/km ） |
| 4×1 | 32/0.20 | 8.80 | 118.80 | 19.61 |
| 4×1.5 | 30/0.25 | 10.50 | 152.60 | 13.42 |
| 4×2.5 | 50/0.25 | 12.60 | 232.20 | 8.03 |
| 5×1 | 32/0.20 | 9.80 | 132.78 | 19.61 |
| 5×1.5 | 30/0.25 | 11.30 | 182.20 | 13.42 |
| 5×2.5 | 50/0.25 | 13.40 | 289.60 | 8.03 |
| 7×1 | 32/0.20 | 11.60 | 168.60 | 19.61 |
| 7×1.5 | 30/0.25 | 13.20 | 262.60 | 13.42 |
| 7×2.5 | 50/0.25 | 15.80 | 328.50 | 8.03 |
| 12×1 | 32/0.20 | 16.20 | 298.20 | 19.61 |
| 12×1.5 | 30/0.25 | 18.40 | 346.80 | 13.42 |
| 12×2.5 | 50/0.25 | 20.60 | 572.40 | 8.03 |
| 19×1 | 32/0.20 | 17.80 | 432.20 | 19.61 |
| 19×1.5 | 30/0.25 | 21.60 | 552.40 | 13.42 |
| 19×2.5 | 50/0.25 | 29.20 | 826.40 | 8.03 |
